Chapter 7 Reconfigurable Optical Add/Drop Cards
7.5.2 32DMX Block Diagram
Figure 7-12 32DMX Faceplate and Ports
7.5.2 32DMX Block Diagram
A block diagram of the 32DMX card is shown in Figure 7-13.
145936
32DMX
FAIL
ACT
SF
54.1-60.6 46.1-52.5 38.1-44.5 30.3-36.6
COM
RX
TX
MON
32 Drop Ports32 Drop Port Outputs
Logical View
Drop 1-8
Drop 9-16
Drop 17-24
Drop 25-32
COM RX
(Receives Drop-TX from
32WSS on COM RX)
COM-RX
Drop-1
Drop-2
Drop-32
