Cisco ONS 15454 DWDM Reference Manual

17-8
Cisco ONS 15454 DWDM Reference Manual, R8.5
78-18343-02
Chapter 17 Performance Monitoring
17.2.2 Payload PM Window
Table 17-5 lists the payload PM parameters that are available on the TXP_MR_2.5G and the
TXPP_MR_2.5G cards when the ONE_GE or FC1G client type is enabled. For PPM provisioning
procedures, refer to the Cisco ONS 15454 DWDM Procedure Guide. For payload definitions, see the
“17.4 Optics and 8b10b PM Parameter Definitions” section on page 17-20 and the “17.6 Full RMON
Statistics PM Parameter Definitions” section on page 17-23.
Note Payload PM is not available for the 2FC client type.
Table 17-6 lists the payload PM parameters that are available on the MXP_MR_2.5G and the
MXPP_MR_2.5G cards when the ONE_GE or the FC1G client type is enabled. For PPM provisioning
procedures, refer to the Cisco ONS 15454 DWDM Procedure Guide. For payload definitions, see the
“17.4 Optics and 8b10b PM Parameter Definitions” section on page 17-20 and the “17.6 Full RMON
Statistics PM Parameter Definitions” section on page 17-23.
Table 17-4 Full RMON Statistics on TXP_MR_10G, TXP_MR_10E, TXP_MR_10E_C,
TXP_MR_10E_L, GE_XP, and 10GE_XP cards
Full RMON Statistics
dot3StatsFCSErrors
dot3StatsFrameTooLong
ifInBroadcastPkts
ifInErrors
ifInErrorsBytePkts
ifInFramingErrorPkts
ifInJunkInterPkts
ifInMulticastPkts
ifInOctets
ifOutBroadcastPkts
ifOutMulticastPkts
ifOutOctets
rxTotalPkts
Time Last Cleared
txTotalPkts
etherStatsBroadcastPkts
etherStatsCRCAlignErrors
etherStatsFragments
etherStatsJabbers
etherStatsMulticastPkts
etherStatsOctets
etherStatsOversizePkts
etherStatsPkts64Octets
etherStatsPkts65to127Octets
etherStatsPkts128to255Octets
etherStatsPkts256to511Octets
etherStatsPkts512to1023Octets
etherStatsPkts1024to1518Octets
etherStatsUndersizePkts
rxControlFrames
rxPauseFrames
rxUnknownOpcodeFrames
Table 17-5 Gigabit Ethernet (GE) or Fibre Channel (FC) Payload PMs for the TXP_MR_2.5G and
TXPP_MR_2.5G Cards
GE or FC Payload Performance Parameters
8b/10bDataOrderedSets
8b/10bIdleOrderedSets
8b/10bNonIdleOrderedSets
8b/10bStatsEncodingDispErrors
ifInErrors
rxTotalPkts

Cisco ONS 15454 DWDM Specifications

General

Chassis Type	DWDM
Form Factor	Rack-mountable
Slots	17
Storage Temperature	-40 to 158°F (-40 to 70°C)
Relative Humidity	5% to 95% non-condensing
Power Supply	AC or DC
Cooling	Internal fans
Operating Temperature	23 to 104°F (-5 to 40°C)
Altitude	0 to 6500 ft (0 to 1981 m)
Safety Compliance	EN 60950-1
EMI Compliance	FCC Part 15
