Chapter 7 Reconfigurable Optical Add/Drop Cards
7.9.2 40-MUX-C Card Block Diagram
Figure 7-24 shows the 40-MUX-C card faceplate.
Figure 7-24 40-MUX-C Card Faceplate
7.9.2 40-MUX-C Card Block Diagram
Figure 7-25 shows a block diagram of the 40-MUX-C card.
40-MUX-C
36.6 - 42.1 30.3 - 35.842.9 - 48.549.3 - 54.955.7 - 61.4
RX
COM
TX
FAIL
ACT
SF
159555
Client ports 1-8
Client ports 9-16
Client ports 17-24
Client ports 25-32
Client ports 33-40
Logical View
COM TX
Client-1
Client-2
Client-40
40 Client Channel Inputs
40 Client Ports
COM TX
Sends combined signal
to OPT- BST

Cisco ONS 15454 DWDM Specifications

General

Chassis Type	DWDM
Form Factor	Rack-mountable
Slots	17
Storage Temperature	-40 to 158°F (-40 to 70°C)
Relative Humidity	5% to 95% non-condensing
Power Supply	AC or DC
Cooling	Internal fans
Operating Temperature	23 to 104°F (-5 to 40°C)
Altitude	0 to 6500 ft (0 to 1981 m)
Safety Compliance	EN 60950-1
EMI Compliance	FCC Part 15
