Cisco ONS 15454 DWDM Reference Manual

15-8
Cisco ONS 15454 DWDM Reference Manual, R8.5
78-18343-02
Chapter 15 Management Network Connectivity
15.2.5 Scenario 5: Using Static Routes to Connect to LANs
Figure 15-5 Scenario 4: Default Gateway on a CTC Computer (ANSI and ETSI)
15.2.5 Scenario 5: Using Static Routes to Connect to LANs
Static routes are used for two purposes:
• To connect ONS 15454s to CTC sessions on one subnet connected by a router to ONS 15454s
residing on another subnet. (These static routes are not needed if OSPF is enabled. Scenario 6 shows
an OSPF example.)
• To enable multiple CTC sessions among ONS 15454s residing on the same subnet.
In Figure 15-6, one CTC residing on subnet 192.168.1.0 connects to a router through interface A (the
router is not set up with OSPF). ONS 15454s residing on different subnets are connected through Node 1
to the router through interface B. Because Nodes 2 and 3 are on different subnets, proxy ARP does not
enable Node 1 as a gateway. To connect to CTC computers on LAN A, a static route is created on
Node 1.
ONS 15454 #1
IP Address 192.168.1.10
Subnet Mask 255.255.255.0
Default Router = N/A
Static Routes = N/A
CTC Workstation
IP Address 192.168.1.100
Subnet Mask at CTC Workstation 255.255.255.0
Default Gateway = 192.168.1.10
Host Routes = N/A
ONS 15454 #2
IP Address 192.168.2.20
Subnet Mask 255.255.255.0
Default Router = N/A
Static Routes = N/A
ONS 15454 #3
IP Address 192.168.3.30
Subnet Mask 255.255.255.0
Default Router = N/A
Static Routes = N/A
LAN A
Ring
124248

Cisco ONS 15454 DWDM Specifications

General

Chassis Type	DWDM
Form Factor	Rack-mountable
Slots	17
Storage Temperature	-40 to 158°F (-40 to 70°C)
Relative Humidity	5% to 95% non-condensing
Power Supply	AC or DC
Cooling	Internal fans
Operating Temperature	23 to 104°F (-5 to 40°C)
Altitude	0 to 6500 ft (0 to 1981 m)
Safety Compliance	EN 60950-1
EMI Compliance	FCC Part 15
