Chapter 3 Optical Service Channel Cards
3.4.2 OSC-CSM Card-Level Indicators
For information on the associated TL1 AIDs for the optical power monitoring points, refer the “CTC
Port Numbers and TL1 Aids” section in Cisco ONS SONET TL1 Command Guide, Release 8.5.
3.4.2 OSC-CSM Card-Level Indicators
The OSC-CSM card has three card-level LED indicators, described in Table 3-6.
3.4.3 OSC-CSM Port-Level Indicators
You can find the status of the card ports using the LCD screen on the ONS 15454 fan-tray assembly. Use
the LCD to view the status of any port or card slot; the screen displays the number and severity of alarms
for a given port or slot. The OSC-CSM has a OC3 port and three other sets of ports located on the
faceplate.
Table 3-5 OSC-CSM Port Calibration
Photodiode CTC Type Name Calibrated to Port
P1 Out Com LINE RX
P2 Input OSC LINE RX
P3 In Com COM RX
P5 Output Osc LINE TX
Table 3-6 OSC-CSM Card-Level Indicators
Card-Level Indicators Description
Red FAIL LED The red FAIL LED indicates that the card’s processor is not ready or that
there is an internal hardware failure. Replace the card if the red FAIL LED
persists.
Green ACT LED The green ACT LED indicates that the OSC-CSM is carrying traffic or is
traffic-ready.
Amber SF LED The amber SF LED indicates a signal failure or condition such as LOS, LOF,
AIS-L, or high BER on one or more of the card’s ports. The amber SF LED
also illuminates when the transmit and receive fibers are incorrectly
connected. When the fibers are properly connected, the light turns off.
