Cisco ONS 15454 DWDM Reference Manual

8-26
Cisco ONS 15454 DWDM Reference Manual, R8.5
78-18343-02
Chapter 8 Transponder and Muxponder Cards
8.7 MXP_2.5G_10G Card
Figure 8-16 MXP_2.5G_10G Faceplate
For information on safety labels for the card, see the “8.2.1 Class 1 Laser Product Cards” section on
page 8-4.
Figure 8-17 shows a block diagram of the MXP_2.5G_10G card.
CLIENT
DWDM
1
2
4x 2.5G
10G MXP
1530.33 -
1531.12
FAIL
ACT/STBY
SF
TX
RX
TX
RX
3
TX
RX
4
TX
RX
!
MAX INPUT
POWER LEVEL
- 8 dBm
TX
RX
1530.33
1531.12
145945

Cisco ONS 15454 DWDM Specifications

General

Chassis Type	DWDM
Form Factor	Rack-mountable
Slots	17
Storage Temperature	-40 to 158°F (-40 to 70°C)
Relative Humidity	5% to 95% non-condensing
Power Supply	AC or DC
Cooling	Internal fans
Operating Temperature	23 to 104°F (-5 to 40°C)
Altitude	0 to 6500 ft (0 to 1981 m)
Safety Compliance	EN 60950-1
EMI Compliance	FCC Part 15
