Cisco ONS 15454 DWDM Reference Manual

5-5
Cisco ONS 15454 DWDM Reference Manual, R8.5
78-18343-02
Chapter 5 Multiplexer and Demultiplexer Cards
5.1.4 Channel Allocation Plan
5.1.4 Channel Allocation Plan
ONS 15454 DWDM multiplexer and demultiplexer cards are designed for use with specific channels in
the C band and L band. In most cases, the channels for these cards are either numbered (for example, 1
to 32 or 1 to 40) or delimited (odd or even). Client interfaces must comply with these channel
assignments to be compatible with the ONS 15454 system.
Table 5-6 lists the channel IDs and wavelengths assigned to the C-band DWDM channels.
Note In some cases, a card uses only one of the bands (C band or L band) and some or all of the channels listed
in a band. Also, some cards use channels on the 100-GHz ITU grid while others use channels on the
50-GHz ITU grid. See the specific card description or Appendix A, “Hardware Specifications” for more
details.
2/4 port GbE
Transponder (GBIC
WDM 100GHz)
+2.5 to
3.5 dBm —
Dispersion
compensation
tolerance
–1200 to
+5400 ps/nm
–1200 to
+5400 ps/nm
–1200 to
+3300
ps/nm
–1200 to
+3300 ps/nm
–1000 to +3600
ps/nm
–1000 to
+3200
ps/nm
1. These values, decreased by patchcord and connector losses, are also the input power values for the OADM cards.
Table 5-5 2.5-Gbps Interface Optical Performance (continued)
Parameter Class D Class E Class F Class G Class H Class J
Type
Power
Limited
OSNR
Limited
Power
Limited
OSNR
Limited
OSNR
Limited
Power
Limited
OSNR
Limited
Power
Limited
OSNR
Limited
Power
Limited
Table 5-6 DWDM Channel Allocation Plan (C Band)
Channel
Number
Frequency
(THz)
Wavelength
(nm)
Channel
Number
Frequency
(THz)
Wavelength
(nm)
1 196.00 1529.55 42 193.95 1545.72
2 195.95 1529.94 43 193.90 1546.119
3 195.90 1530.334 44 193.85 1546.518
4 195.85 1530.725 45 193.80 1546.917
5 195.80 1531.116 46 193.75 1547.316
6 195.75 1531.507 47 193.70 1547.715
7 195.70 1531.898 48 193.65 1548.115
8 195.65 1532.290 49 193.60 1548.515
9 195.60 1532.681 50 193.55 1548.915
10 195.55 1533.073 51 193.50 1549.32
11 195.50 1533.47 52 193.45 1549.71
12 195.45 1533.86 53 193.40 1550.116
13 195.40 1534.250 54 193.35 1550.517

Cisco ONS 15454 DWDM Specifications

General

Chassis Type	DWDM
Form Factor	Rack-mountable
Slots	17
Storage Temperature	-40 to 158°F (-40 to 70°C)
Relative Humidity	5% to 95% non-condensing
Power Supply	AC or DC
Cooling	Internal fans
Operating Temperature	23 to 104°F (-5 to 40°C)
Altitude	0 to 6500 ft (0 to 1981 m)
Safety Compliance	EN 60950-1
EMI Compliance	FCC Part 15
