Cisco ONS 15454 DWDM - Payload PM Statistics Window

17-7
Cisco ONS 15454 DWDM Reference Manual, R8.5
78-18343-02
Chapter 17 Performance Monitoring
17.2.2 Payload PM Window
17.2.2.2 Payload PM Statistics Window
Table 17-4 lists the 10 Gigabit Ethernet (10 GE) payload statistics that are available on the
TXP_MR_10G, TXP_MR_10E, TXP_MR_10E_C, and TXP_MR_10E_L cards. PPM provisioning
must be completed under the card view Provisioning > Pluggable Port Modules tab for 10 GE to be
enabled. For PPM provisioning procedures, refer to the Cisco ONS 15454 DWDM Procedure Guide. The
parameters are listed under card view on the Performance > Payload PM > Statistics tab. For 10 GE
payload definitions, see Table 17-27 on page 17-23.
Note Utilization PMs are also available per port.
Table 17-3 ONS 15454 SONET/SDH Layer Far-End and Near-End PMs
SONET
Layer Far-End (FE)
1, 2
1. Applicable to optical channel (OCH) and Client (CLNT) facilities.
2. For MXP_MR_2.5G and MXPP_MR_2.5G cards, these parameters are shown in the Performance > Payload PM > SONET
PM tabs in the card view.
Layer Near-End
1, 2
Note
CV-LFE
ES-LFE
FC-LFE
SES-LFE
UAS-LFE
CV-L
CV-S
ES-L
ES-S
FC-L
SES-L
SES-S
SEF-S
UAS-L
Applicable standard is
Telcordia GR-253.
SDH MS-BBE
MS-BBER
MS-EB
MS-ES
MS-ESR
MS-SES
MS-SESR
MS-UAS
RS-BBE
RS-BBER
RS-EB
RS-ES
RS-ESR
RS-SES
RS-SESR
RS-UAS
MS-BBE
MS-BBER
MS-EB
MS-ES
MS-ESR
MS-SES
MS-SESR
MS-UAS
Applicable standard is
Telcordia GR-253.
