Appendix A Hardware Specifications
A.9.6 MXP_2.5G_10E_C Card Specifications
–
Code: Scrambled NRZ
–
Fiber: 1550-nm single-mode
–
Maximum chromatic dispersion allowance: +/– 1200 ps/nm (specified penalty)
–
Loopback modes: Terminal and facility
Caution You must use a 20-dB fiber attenuator (15 to 25 dB) when working with the MXP_2.5G_10E_C card in
a loopback on the trunk port. Do not use direct fiber loopbacks with the MXP_2.5G_10E_C card. Using
direct fiber loopbacks causes irreparable damage to the card.
–
Connectors: LC
• Transmitter (trunk side)
–
Maximum transmitter output power: +6 dBm
–
Minimum transmitter output power: +3 dBm
–
Transmitter: LN external modulator transmitter
–
Wavelength stability (drift): +/– 25 picometers (pm)
Note An optical device on the card keeps the laser wavelength locked as closely as possible to the ITU nominal
value. The allowed drift is +/– 25 pm.
• Currently available wavelengths and versions of MXP_2.5G_10E_C card:
There is a single version of the MXP_2.5G_10E_C card. It is tunable across 82 wavelengths in the
C-band frequency plan, with channels on the ITU 50-GHz grid, as shown in Table A-35.
Table A-35 MXP_2.5G_10E_C Card Trunk Wavelengths
Channel
Number
Frequency
(THz)
Wavelength
(nm)
Channel
Number
Frequency
(THz)
Wavelength
(nm)
1 196.00 1529.55 42 193.95 1545.72
2 195.95 1529.94 43 193.90 1546.119
3 195.90 1530.334 44 193.85 1546.518
4 195.85 1530.725 45 193.80 1546.917
5 195.80 1531.116 46 193.75 1547.316
6 195.75 1531.507 47 193.70 1547.715
7 195.70 1531.898 48 193.65 1548.115
8 195.65 1532.290 49 193.60 1548.515
9 195.60 1532.681 50 193.55 1548.915
10 195.55 1533.073 51 193.50 1549.32
11 195.50 1533.47 52 193.45 1549.71
12 195.45 1533.86 53 193.40 1550.116
13 195.40 1534.250 54 193.35 1550.517
14 195.35 1534.643 55 193.30 1550.918
