Cisco ONS 15454 DWDM Reference Manual, R8.5
78-18343-02
Appendix A Hardware Specifications
A.9.6 MXP_2.5G_10E_C Card Specifications
• Receiver (trunk side, see Table A-36)
15 195.30 1535.036 56 193.25 1551.319
16 195.25 1535.429 57 193.20 1551.721
17 195.20 1535.822 58 193.15 1552.122
18 195.15 1536.216 59 193.10 1552.524
19 195.10 1536.609 60 193.05 1552.926
20 195.05 1537.003 61 193.00 1553.33
21 195.00 1537.40 62 192.95 1553.73
22 194.95 1537.79 63 192.90 1554.134
23 194.90 1538.186 64 192.85 1554.537
24 194.85 1538.581 65 192.80 1554.940
25 194.80 1538.976 66 192.75 1555.343
26 194.75 1539.371 67 192.70 1555.747
27 194.70 1539.766 68 192.65 1556.151
28 194.65 1540.162 69 192.60 1556.555
29 194.60 1540.557 70 192.55 1556.959
30 194.55 1540.953 71 192.50 1557.36
31 194.50 1541.35 72 192.45 1557.77
32 194.45 1541.75 73 192.40 1558.173
33 194.40 1542.142 74 192.35 1558.578
34 194.35 1542.539 75 192.30 1558.983
35 194.30 1542.936 76 192.25 1559.389
36 194.25 1543.333 77 192.20 1559.794
37 194.20 1543.730 78 192.15 1560.200
38 194.15 1544.128 79 192.10 1560.606
39 194.10 1544.526 80 192.05 1561.013
40 194.05 1544.924 81 192.00 1561.42
41 194.00 1545.32 82 191.95 1561.83
Table A-35 MXP_2.5G_10E_C Card Trunk Wavelengths (continued)
Channel
Number
Frequency
(THz)
Wavelength
(nm)
Channel
Number
Frequency
(THz)
Wavelength
(nm)
Table A-36 MXP_2.5G_10E_C Card Receiver Trunk Side Specifications
OSNR
1
FEC Type Pre-FEC BER Post-FEC BER
Input Power
Sensitivity
2
Chromatic Dispersion
Tolerance
30 dB Off < 10 exp – 12 N/A – 8 to – 20 dBm +/– 1200 ps/nm
26 dB Off < 10 exp – 12 N/A – 8 to – 20 dBm +/– 1000 ps/nm
26 dB Off < 10 exp – 12 N/A – 8 to – 22 dBm —
