A.9.11 TXP_MR_10E_C Card Specifications
–
Minimum transmitter output power: +3 dBm
–
Transmitter: LN external modulator transmitter
–
Wavelength stability (drift): +/– 25 picometers (pm)
Note An optical device on the card keeps the laser wavelength locked as closely as possible to the ITU nominal
value. The allowed drift is +/– 25 pm.
• Currently available wavelengths and versions of TXP_MR_10E_C card:
There is a single version of the TXP_MR_10E_C card. It is tunable across 82 wavelengths in the
C-band frequency plan, with channels on the ITU 50-GHz grid, as shown in Table A-42.
Table A-42 TXP_MR_10E_C Card Trunk Wavelengths
Channel
Number
Frequency
(THz)
Wavelength
(nm)
Channel
Number
Frequency
(THz)
Wavelength
(nm)
1 196.00 1529.55 42 193.95 1545.72
2 195.95 1529.94 43 193.90 1546.119
3 195.90 1530.334 44 193.85 1546.518
4 195.85 1530.725 45 193.80 1546.917
5 195.80 1531.116 46 193.75 1547.316
6 195.75 1531.507 47 193.70 1547.715
7 195.70 1531.898 48 193.65 1548.115
8 195.65 1532.290 49 193.60 1548.515
9 195.60 1532.681 50 193.55 1548.915
10 195.55 1533.073 51 193.50 1549.32
11 195.50 1533.47 52 193.45 1549.71
12 195.45 1533.86 53 193.40 1550.116
13 195.40 1534.250 54 193.35 1550.517
14 195.35 1534.643 55 193.30 1550.918
15 195.30 1535.036 56 193.25 1551.319
16 195.25 1535.429 57 193.20 1551.721
17 195.20 1535.822 58 193.15 1552.122
18 195.15 1536.216 59 193.10 1552.524
19 195.10 1536.609 60 193.05 1552.926
20 195.05 1537.003 61 193.00 1553.33
21 195.00 1537.40 62 192.95 1553.73
22 194.95 1537.79 63 192.90 1554.134
23 194.90 1538.186 64 192.85 1554.537
24 194.85 1538.581 65 192.80 1554.940
25 194.80 1538.976 66 192.75 1555.343
26 194.75 1539.371 67 192.70 1555.747
