Chapter 9 Node Reference
9.5.2 Hub Node Fiber-Optic Cabling
9.5.2 Hub Node Fiber-Optic Cabling
The following rules generally apply to hub node cabling:
• The Side A OPT-BST or OSC-CSM card common (COM) TX port is connected to the Side A
OPT-PRE COM RX port or the Side A 32DMX-O/40-DMX-C/40-DMX-CE COM RX port.
• The Side A OPT-PRE COM TX port is connected to the Side A 32DMX-O/40-DMX-C/40-DMX-CE
COM RX port.
• The Side A 32MUX-O/32WSS/32WSS-L COM TX port is connected to the Side A OPT-BST or
Side A OSC-CSM COM RX port.
• The Side B 32MUX-O/32WSS/32WSS-L COM TX port is connected to the Side B OPT-BST or
Side B OSC-CSM COM RX port.
• The Side B OPT-BST or Side B OSC-CSM COM TX port is connected to the Side B OPT-PRE COM
RX port or the Side B 32DMX-O/32DMX COM RX port.
• The Side B OPT-PRE COM TX port is connected to the Side B 32DMX-O/32DMX COM RX port.
Figure 9-34 shows an example of a hub node with cabling. In the example, OSCM cards are installed. If
OSC-CSM cards are installed, they are usually installed in Slots 1 and 17.
2 Side A OPT-BST LINE TX to Side B OPT-BST or
OSC-CSM LINE RX on adjacent node
6 Side B OSCM RX to Side B OPT-BST OSC TX
3 Side A OPT-BST OSC TX to Side A OSCM RX 7 Side B OPT-BST LINE TX to Side A OPT-BST
or OSC-CSM LINE RX on adjacent node
4 Side A OPT-BST OSC RX to Side A OSCM TX 8 Side B OPT-BST LINE RX to Side A OPT-BST
or OSC-CSM LINE TX on adjacent node

Cisco ONS 15454 DWDM Specifications

General

Chassis Type	DWDM
Form Factor	Rack-mountable
Slots	17
Storage Temperature	-40 to 158°F (-40 to 70°C)
Relative Humidity	5% to 95% non-condensing
Power Supply	AC or DC
Cooling	Internal fans
Operating Temperature	23 to 104°F (-5 to 40°C)
Altitude	0 to 6500 ft (0 to 1981 m)
Safety Compliance	EN 60950-1
EMI Compliance	FCC Part 15
