CHAPTER
10-1
Cisco ONS 15454 DWDM Reference Manual, R8.5
78-18343-02
10
Network Reference
This chapter explains the ONS 15454 dense wavelength division multiplexing (DWDM) network
applications and topologies. The chapter also provides network-level optical performance references.
Note Unless otherwise specified, “ONS 15454” refers to both ANSI and ETSI shelf assemblies.
Note In this chapter, “OPT-BST” refers to the OPT-BST, OPT-BST-E, OPT-BST-L cards, and to the
OPT-AMP-L, OPT-AMP-C, and OPT-AMP-17-C cards when they are provisioned in OPT-LINE (optical
booster) mode. “OPT-PRE” refers to the OPT-PRE card and to the OPT-AMP-L, OPT-AMP-C, and
OPT-AMP-17-C cards provisioned in OPT-PRE (pre-amplifier) mode.
Note OPT-BST-L, 32WSS-L, 32DMX-L, and OPT-AMP-L cards can only be installed in L-band-compatible
nodes and networks. OPT-BST, OPT-BST-E, 32WSS, 32DMX, 40-DMX-C, 40-DMX-CE, 40-MUX-C,
40-WSS-C, 40-WSS-CE, 40-WXC-C, OPT-AMP-C, and OPT-AMP-17-C cards can only be installed in
C-band-compatible nodes and networks.
Chapter topics include:
• 10.1 Network Applications, page 10-2
• 10.2 Network Topologies, page 10-2
• 10.3 Optical Performance, page 10-9
• 10.4 Automatic Power Control, page 10-10
• 10.5 ROADM Power Equalization Monitoring, page 10-16
• 10.6 Span Loss Verification, page 10-17
• 10.7 Network Optical Safety, page 10-18
• 10.8 Network-Level Gain—Tilt Management of Optical Amplifiers, page 10-28
• 10.9 Optical Data Rate Derivations, page 10-34
• 10.10 Even Band Management, page 10-36
