Cisco ONS 15454 DWDM Reference Manual

11-9
Cisco ONS 15454 DWDM Reference Manual, R8.5
78-18343-02
Chapter 11 Optical Channel Circuits and Virtual Patchcords Reference
11.2 Virtual Patchcords
PPCs are created and managed from the network view Provisioning > Provisionable Patchcord (PPC) tab
(Figure 11-4), or from the node view (single-shelf mode) or multiself view (multishelf mode)
Provisioning > Comm Channel > PPC tab.
32WSS
32WSS-L
40-WSS-C
40-WSS-CE
— Any ADD port COM-TX
COM-RX
EXP-TX
EXP-RX
DROP-TX
40-WXC-C — — ADD-RX
DROP-TX
COM TX
COM RX
MMU — — EXP A TX
EXP A RX
1. When provisioned in OPT-PRE mode.
Table 11-3 Internal Patchcord Ports (continued)
Card OCH Trunk Ports OCH Filter Ports OTS/OCH Ports

Cisco ONS 15454 DWDM Specifications

General

Chassis Type	DWDM
Form Factor	Rack-mountable
Slots	17
Storage Temperature	-40 to 158°F (-40 to 70°C)
Relative Humidity	5% to 95% non-condensing
Power Supply	AC or DC
Cooling	Internal fans
Operating Temperature	23 to 104°F (-5 to 40°C)
Altitude	0 to 6500 ft (0 to 1981 m)
Safety Compliance	EN 60950-1
EMI Compliance	FCC Part 15
