Chapter 15 Management Network Connectivity
15.2.8 Scenario 8: Dual GNEs on a Subnet
Figure 15-13 Scenario 8: Dual GNEs on the Same Subnet (ANSI and ETSI)
124256
Remote CTC
10.10.20.10
10.10.20.0/24
10.10.10.0/24
Interface 0/0
10.10.20.1
Router A
Interface 0/1
10.10.10.1
ONS 15454
Gateway NE
10.10.10.100/24
ONS 15454
End NE
10.10.10.250/24
ONS 15454
Gateway NE
10.10.10.150/24
ONS 15454
End NE
10.10.10.200/24
Local/Craft CTC
192.168.20.20
Ethernet
Optical Fiber
