Cisco ONS 15454 DWDM Reference Manual

B-9
Cisco ONS 15454 DWDM Reference Manual, R8.5
78-18343-02
Appendix B Administrative and Service States
B.3.3 Optical Payload Port Service State Transitions
OOS-AU,FLT (ANSI)
Unlocked-disabled,failed (ETSI)
Alarm/condition is cleared. IS-NR (ANSI)
Unlocked-enabled (ETSI)
Put the port or cross-connect in
the IS,AINS (ANSI) or
Unlocked,automaticInService
(ETSI) administrative state.
OOS-AU,AINS & FLT (ANSI)
Unlocked-disabled,automaticInService &
failed (ETSI)
Put the port or cross-connect in
the OOS,DSBLD (ANSI) or
Locked,disabled (ETSI)
administrative state.
OOS-MA,DSBLD (ANSI)
Locked-enabled,disabled (ETSI)
Put the port or cross-connect in
the OOS,MT (ANSI) or
Locked,maintenance (ETSI)
administrative state.
OOS-AUMA,FLT & MT (ANSI)
Locked-disabled,failed & maintenance
(ETSI)
OOS-AUMA,FLT & LPBK & MT (ANSI)
Locked-disabled,failed & loopback &
maintenance (ETSI)
Release the loopback. OOS-AUMA,FLT & MT (ANSI)
Locked-disabled,failed & maintenance
(ETSI)
Alarm/condition is cleared. OOS-MA,LPBK & MT (ANSI)
Locked-enabled,loopback & maintenance
(ETSI)
OOS-AUMA,FLT & MT (ANSI)
Locked-disabled,failed & maintenance
(ETSI)
Alarm/condition is cleared. OOS-MA,MT (ANSI)
Locked-enabled,maintenance (ETSI)
Put the port or cross-connect in
the IS (ANSI) or
Unlocked-enabled (ETSI)
administrative state.
OOS-AU,FLT (ANSI)
Unlocked-disabled,failed (ETSI)
Put the port or cross-connect in
the IS,AINS (ANSI) or
Unlocked,automaticInService
(ETSI) administrative state.
OOS-AU,AINS & FLT (ANSI)
Unlocked-disabled,automaticInService &
failed (ETSI)
Put the port or cross-connect in
the OOS,DSBLD (ANSI) or
Locked,disabled (ETSI)
administrative state.
OOS-MA,DSBLD (ANSI)
Locked-enabled,disabled (ETSI)
Put the port or cross-connect in a
loopback.
OOS-AUMA,FLT & LPBK & MT (ANSI)
Locked-disabled,failed & loopback &
maintenance (ETSI)
Table B-6 ONS 15454 Optical Payload Port Service State Transitions (continued)
Current Service State Action Next Service State

Cisco ONS 15454 DWDM Specifications

General

Chassis Type	DWDM
Form Factor	Rack-mountable
Slots	17
Storage Temperature	-40 to 158°F (-40 to 70°C)
Relative Humidity	5% to 95% non-condensing
Power Supply	AC or DC
Cooling	Internal fans
Operating Temperature	23 to 104°F (-5 to 40°C)
Altitude	0 to 6500 ft (0 to 1981 m)
Safety Compliance	EN 60950-1
EMI Compliance	FCC Part 15
