7-8
Cisco ONS 15454 DWDM Reference Manual, R8.5
78-18343-02
Chapter 7 Reconfigurable Optical Add/Drop Cards
7.1.4 Channel Allocation Plans
The following add drop cards utilize the L band DWDM channels:
• 32WSS-L
• 32DMX-L
Table 7-7 lists the L band channel IDs and wavelengths at ITU-T 50-GHz intervals. This is a
comprehensive L band channel table that encompasses future card capability as well as present
capabilities.
31 194.50 1541.35 72 192.45 1557.77
32 194.45 1541.75 73 192.40 1558.173
33 194.40 1542.142 74 192.35 1558.578
34 194.35 1542.539 75 192.30 1558.983
35 194.30 1542.936 76 192.25 1559.389
36 194.25 1543.333 77 192.20 1559.794
37 194.20 1543.730 78 192.15 1560.200
38 194.15 1544.128 79 192.10 1560.606
39 194.10 1544.526 80 192.05 1561.013
40 194.05 1544.924 81 192.00 1561.42
41 194.00 1545.32 82 191.95 1561.83
1. Channels on the C band are 4-skip-1, starting at 1530.33 nm.
Table 7-6 DWDM C
1
Band Channel Allocation Plan with 50-GHz Spacing (continued)
Channel
Number
Frequency
(THz)
Wavelength
(nm)
Channel
Number
Frequency
(THz) Wavelength (nm)
Table 7-7 DWDM L Band
1
Channel Allocation Plan at 50 GHz Spacing
Channel
Number
Frequency
(THz)
Wavelength
(nm)
Channel
Number
Frequency
(THz) Wavelength (nm)
1 190.85 1570.83 41 188.85 1587.46
2 190.8 1571.24 42 188.8 1587.88
3 190.75 1571.65 43 188.75 1588.30
4 190.7 1572.06 44 188.7 1588.73
5 190.65 1572.48 45 188.65 1589.15
6 190.6 1572.89 46 188.6 1589.57
7 190.55 1573.30 47 188.55 1589.99
8 190.5 1573.71 48 188.5 1590.41
9 190.45 1574.13 49 188.45 1590.83
10 190.4 1574.54 50 188.4 1591.26
11 190.35 1574.95 51 188.35 1591.68
12 190.3 1575.37 52 188.3 1592.10
13 190.25 1575.78 53 188.25 1592.52
