Cisco ONS 15454 DWDM Reference Manual

9-5
Cisco ONS 15454 DWDM Reference Manual, R8.5
78-18343-02
Chapter 9 Node Reference
9.1.2 Terminal Node
Figure 9-3 Hub Node Channel Flow Example
9.1.2 Terminal Node
A terminal node is a single ONS 15454 node equipped with two TCC2/TCC2P cards and one of the
following combinations:
• One 32MUX-O card and one 32DMX-O card
• One 32WSS card and either a 32DMX or a 32DMX-O card
• One 32WSS-L card and one 32DMX-L card
• One 40-WSS-C or 40-WSS-CE card and one 40-DMX-C or 40-DMX-CE card
• One 40-MUX-C and one 40-DMX-C or 40-DMX-CE card
Cards in the terminal nodes can be installed in Slots 1 through 6 or Slots 12 through 17. The side where
cards are installed is always assigned as Side A. Figure 9-4 shows an example of a terminal configuration
with a 2MUX-O card installed. The channel flow for a terminal node is the same as the hub node
(Figure 9-3).
Client
equipment
32DMX-0
32MUX-0
32MUX-0
32DMX-0
OPT-PRE
OPT-PRE
OPT-BST
West side
East side
OPT-BST
Line
Line
96426
DCU
OSCM
TCC
TCC2
OSCM
AIC-I
DCU

Cisco ONS 15454 DWDM Specifications

General

Chassis Type	DWDM
Form Factor	Rack-mountable
Slots	17
Storage Temperature	-40 to 158°F (-40 to 70°C)
Relative Humidity	5% to 95% non-condensing
Power Supply	AC or DC
Cooling	Internal fans
Operating Temperature	23 to 104°F (-5 to 40°C)
Altitude	0 to 6500 ft (0 to 1981 m)
Safety Compliance	EN 60950-1
EMI Compliance	FCC Part 15
