Cisco ONS 15454 DWDM Reference Manual

9-53
Cisco ONS 15454 DWDM Reference Manual, R8.5
78-18343-02
Chapter 9 Node Reference
9.5.6 Amplified or Passive OADM Node Fiber-Optic Cabling
Figure 9-38 shows an example of a passive OADM node with two AD-1C-xx.x cards installed.
4 Side A OPT-BST COM RX to Side A AD-1C-xx.x
COM TX
12 Side B AD-1C-xx.x COM RX to OPT-PRE COM TX
5 Side A OPT-PRE COM TX to Side A AD-1C-xx.x
COM RX
13 Side B AD-1C-xx.x COM TX to OPT-BST COM RX
6 Side A AD-1C-xx.x (15xx.xx) RX to Side A
TXP_MR_2.5G DWDM TX
14 Side B OPT-PRE COM RX to Side B OPT-BST
COM TX
7 Side A AD-1C-xx.x (15xx.xx) TX to Side A
TXP_MR_2.5G DWDM RX
15 Side B DCU TX to Side B OPT-PRE DC RX
1
8 Side A AD-1C-xx.x EXP TX to Side B AD-1C-xx.x
EXP RX
16 Side B DCU RX to Side B OPT-PRE DC TX
1
1. If a DCU is not installed, a 4-dB attenuator loop, +/ 1 dB, must be installed between the OPT-PRE DC ports.

Cisco ONS 15454 DWDM Specifications

General

Chassis Type	DWDM
Form Factor	Rack-mountable
Slots	17
Storage Temperature	-40 to 158°F (-40 to 70°C)
Relative Humidity	5% to 95% non-condensing
Power Supply	AC or DC
Cooling	Internal fans
Operating Temperature	23 to 104°F (-5 to 40°C)
Altitude	0 to 6500 ft (0 to 1981 m)
Safety Compliance	EN 60950-1
EMI Compliance	FCC Part 15
