Cisco ONS 15454 DWDM Reference Manual

liii
Cisco ONS 15454 DWDM Reference Manual, R8.5
78-18343-02
Preface
November 2009 • Updated the section “32WSS Block Diagram” in the chapter
“Reconfigurable Optical Add/Drop Cards”.
• Added a note in “GE_XP, 10GE_XP, GE_XPE, and 10GE_XPE Cards”
section of chapter, Transponder and Muxponder Cards.
• Updated the table "2R and 3R Mode and ITU-T G.709 Compliance by
Client Interface" in chapter, Transponder and Muxponder Cards.
• Updated the table “Card View Tabs and Subtabs” in Chapter, Cisco
Transport Controller Operation.
• Updated the section “Layer 2 Over DWDM Protection” in the chapter
“Transponder and Muxponder Cards”.
February 2010
• Changed the BIEC parameter to BIT-EC in Chapter 17, “Performance
Monitoring”.
• Updated the SFP/XFP Card Compatibility table for ADM-10G card in
chapter Transponder and Muxponder Cards.
March 2010
• Updated the section “Client Interface” under the section “GE_XP and
10GE_XP Cards” in the chapter “Transponder and Muxponder Cards”.
• Added the section, “Mesh Patch Panel Specifications” in the appendix,
Hardware Specifications.
• Updated the table “Multimode Fiber SFP Port Cabling Specifications” in
the appendix “Hardware Specifications”.
April 2010
• Updated the section “SNMP Overview” in the chapter “SNMP”.
• Created a section “Fan Tray Units for ONS 15454 Cards” in the chapter
“Shelf Assembly Hardware”.
• Added footnote and note for ONS-SC-2G-28.7 SFP in the chapter
“Transponder and Muxponder Cards” and appendix “Hardware
Specifications”.
June 2010
• Updated the table “ONS 15454 Security Levels—Node View” in the
chapter “Security Reference”.
July 2010
• Updated the section, Y-cable protection in the chapter, Transponder and
Muxponder Cards.
August 2010
• Updated the table “Node View (Single-Shelf Mode) or Shelf View
(Multishelf Mode) Tabs and Subtab” in the chapter, “Cisco Transport
Controller Operation”.
September 2010
• Added the FAPS switching criteria in the section, “Layer 2 Over DWDM
Protection” in the chapter, “Transponder and Muxponder Cards”.
Date Notes

Cisco ONS 15454 DWDM Specifications

General

Chassis Type	DWDM
Form Factor	Rack-mountable
Slots	17
Storage Temperature	-40 to 158°F (-40 to 70°C)
Relative Humidity	5% to 95% non-condensing
Power Supply	AC or DC
Cooling	Internal fans
Operating Temperature	23 to 104°F (-5 to 40°C)
Altitude	0 to 6500 ft (0 to 1981 m)
Safety Compliance	EN 60950-1
EMI Compliance	FCC Part 15
