A-76
Cisco ONS 15454 DWDM Reference Manual, R8.5
78-18343-02
Appendix A Hardware Specifications
A.9.12 TXP_MR_10E_L Card Specifications
Caution You must use a 15-dB fiber attenuator (10 to 20 dB) when working with the TXP_MR_10E_L
card in a loopback on the trunk port. Do not use direct fiber loopbacks with the
TXP_MR_10E_L card. Using direct fiber loopbacks causes irreparable damage to the
TXP_MR_10E_L card.
–
Connectors: LC
• Transmitter (trunk side)
–
Maximum transmitter output power: +6 dBm
–
Minimum transmitter output power: +2 dBm
–
Transmitter: LN external modulator transmitter
–
Wavelength stability (drift): +/– 25 picometers (pm)
Note An optical device on the card keeps the laser wavelength locked as closely as possible to the ITU nominal
value. The allowed drift is +/– 25 pm.
• Currently available wavelengths and versions of TXP_MR_10E_L card:
There is a single version of the TXP_MR_10E_L card. It is tunable across 80 wavelengths in the
L band frequency plan, with channels on the ITU 50-GHz grid, as shown in Table A-44.
Table A-44 TXP_MR_10E_L Card Trunk Wavelengths
Channel
Number
Frequency
(THz)
Wavelength
(nm)
Channel
Number
Frequency
(THz)
Wavelength
(nm)
1 190.85 1570.83 41 188.85 1587.46
2 190.8 1571.24 42 188.8 1587.88
3 190.75 1571.65 43 188.75 1588.30
4 190.7 1572.06 44 188.7 1588.73
5 190.65 1572.48 45 188.65 1589.15
6 190.6 1572.89 46 188.6 1589.57
7 190.55 1573.30 47 188.55 1589.99
8 190.5 1573.71 48 188.5 1590.41
9 190.45 1574.13 49 188.45 1590.83
10 190.4 1574.54 50 188.4 1591.26
11 190.35 1574.95 51 188.35 1591.68
12 190.3 1575.37 52 188.3 1592.10
13 190.25 1575.78 53 188.25 1592.52
14 190.2 1576.20 54 188.2 1592.95
15 190.15 1576.61 55 188.15 1593.37
16 190.1 1577.03 56 188.1 1593.79
17 190.05 1577.44 57 188.05 1594.22
18 190 1577.86 58 188 1594.64
