5.2.2 List of universal timer unit 1 registers
Register base address for unit 1: 0x400420 00
Offset address
Register name
R/W
Bit width
Reset value
0x180
TCR10
R
16
FFFFH
0x182
TCR11
R
16
FFFFH
0x184
TCR12
R
16
FFFFH
0x186
TCR13
R
16
FFFFH
0x190
TMR10
R/W
16
0000H
0x192
TMR11
R/W
16
0000H
0x194
TMR12
R/W
16
0000H
0x196
TMR13
R/W
16
0000H
0x1A0
TSR10
R
16
0000H
0x1A0
TSR10L
R
8
00H
0x1A2
TSR11
R
16
0000H
0x1A2
TSR11L
R
8
00H
0x1A4
TSR12
R
16
0000H
0x1A4
TSR12L
R
8
00H
0x1A6
TSR13
R
16
0000H
0x1A6
TSR13L
R
8
00H
0x1B0
TE1
R
16
0000H
0x1B0
TE1L
R
8
00H
0x1B2
TS1
R/W
16
0000H
0x1B2
TS1L
R/W
8
00H
0x1B4
TT1
R/W
16
0000H
0x1B4
TT1L
R/W
8
00H
0x1B6
TPS1
R/W
16
0000H
0x1B8
TO1
R/W
16
0000H
0x1B8
TO1L
R/W
8
00H
0x1BA
TOE1
R/W
16
0000H
0x1BA
TOE1L
R/W
8
00H
0x1BC
TOL1
R/W
16
0000H
0x1BC
TOL1L
R/W
8
00H
0x1BE
TOM1
R/W
16
0000H
0x1BE
TOM1L
R/W
8
00H
0x318
TDR10
R/W
16
0000H
0x31A
TDR11
R/W
16
0000H
0x31A
TDR11L
R/W
8
00H
0x31B
TDR11H
R/W
8
00H
0x364
TDR12
R/W
16
0000H
0x366
TDR13
R/W
16
0000H
0x366
TDR13L
R/W
8
00H
0x367
TDR13H
R/W
8
00H
