CMS32L051 User Manual |Chapter 17 Linkage Controller (EVENTC)
www.mcu.com.cn 607 / 703
17.3.1 Output target selection register n (ELSELRn) (n=00~14)
The ELSELRn register links each event signal to the event receiver peripheral function (link target
peripheral function) to run when the event accepts the event. You cannot link multiple event inputs to
the same event output destination (event acceptor). Otherwise, the event receiver's peripheral
functionality may operate uncertainly and the event signal may not be accepted properly. Also, you
cannot set the event link occurrence source and event output destination to the same function.
The ELSELRn register must be set during the period when the peripheral functions of all event
outputs do not generate an event signal.
The correspondence between the ELSELRn register (n=00~14) and the peripheral functions is
shown in Table 17-2. The corresponding operation between the config value of the ELSELRn register
(n=00 ~14) and the link target peripheral function when receiving the event is shown Table 17-3.
Figure 17-2 Format of event output target selection register n (ELSELRn)
Address: 40043400H(ELSELR00) ~ 4004340EH (ELSELR14) After reset: 00H
R/W
symbol
7
6
5
4
3
2
1
0
ELSELRn
0
0
0
0
0
ELSELn2
ELSELn1
ELSELn0
ELSELn2
ELSELn1
ELSELn0
Selection of event links
0
0
0
Disable event linking.
0
0
1
Selection of the linked peripheral function 1
operation
Note 1
.
0
1
0
Selection of the linked peripheral function 2
operation
Note 1
.
0
1
1
Selection of the linked peripheral function 3
operation
Note 1
.
1
0
0
Selection of the linked peripheral function 4
operation
Note 1
.
other
Set Prohibited
Note 1 Please refer to Table 17-3 Correspondence between the setting value of ELSELRn register
(n=00~14) and the operation when the link target peripheral function accepts the event
