V1.2.2

CMS32L051 User Manual |Chapter 26 Option Byte

www.mcu.com.cn 694 / 703

26.3 Format of flash data protection option bytes

The format of the Flash Data Protection Options byte is as follows.

Figure 26-4 Format of flash data protection option bytes (000C3H)

Address: 000C3H

Symbol

7 6 5 4 3 2 1 0

OCD[7:0]

Address: 500004H

Symbol

7 6 5 4 3 2 1 0

OCDM[7:0]

OCDM

OCDEN

Control of flash data protection

It is not allowed to manipulate flash data throughd-ebuggers.

A value other

than 3C

Allows chip full erase operation of flash data through debugger, and does not

allow read and write operations.

Beyond the above

Allows read/write/erase operations on flash data via debugger

Notice The address 50_0004H belongs to the data flash area. If you use this address for data storage, you need to make

sure that the value will not cause the protection option to be set by mistake first.
