16.3.8 DMA transmit count reload register j(DMRLDj) (j=0~23).

This register sets the initial value of the number of transfers register in repeat mode. In repeat

mode, because the value of this register is reloaded into the DMACT register, the set value must be the

same as the initial value of the DMACT register.

Figure 16-9 Format of DMA transmit count reload register j (DMRLDj)

Address:

Refer to 16.3.2

Control data allocation

.

After reset: Indefinite value

R/W

Symbol:

DMRLDj

DMRLDj15

DMRLDj14

DMRLDj13

DMRLDj12

DMRLDj11

DMRLDj10

DMRLDj9

DMRLDj8

DMRLDj7

DMRLDj6

DMRLDj5

DMRLDj4

DMRLDj3

DMRLDj2

DMRLDj1

DMRLDj0

Note 1. DMRLDj register access is not possible via DMA transfer.
