V1.2.2

CMS32L051 User Manual |Chapter 16 Enhanced DMA

www.mcu.com.cn 586 / 703

16.3.7 DMA transmit count register j(DMACTj) (j=0~23)

This register sets the number of data transfers to the DMA. Decrements 1 for every DMA transfer started.

Figure 16-8 Format of DMA transmit count register J (DMACTj).

Symbol:

DMACTj

DMACTj15

DMACTj14

DMACTj13

DMACTj12

DMACTj11

DMACTj1

DMACTj9

DMACTj

DMACTj7

DMACTj6

DMACTj5

DMACTj4

DMACTj3

DMACTj2

DMACTj1

DMACTj0

Address: Refer to 16.3.2

Control data allocation

.

After reset: Indefinite value

R/W

DMACTj

Number of transfers

00H

Disable the setting

01H

1 time

02H

2 times

03H

3 times



FDH

253 times

FEH

254 times

FFH

255 times



FFFFH

65535 times

Note 1 DMACTj registers cannot be accessed via DMA transfer.
