CMS32L051 User Manual |Chapter 16 Enhanced DMA
www.mcu.com.cn 596 / 703
16.4.3 Repeat pattern
The transfer data for one initiation is 1 to 65535 bytes. The source or destination is designated as a
repeat area, and the number of transfers is 1 to 65535 times. Once the specified number of transfers is
complete, initialize the DMACTj(j=0~23) register and the address specified as a repeat, and then repeat
the transfer. This is when the RPTINT bit of the DMACRj register is 1 (interrupts are allowed) and a data
transfer is made where the DMACTj register becomes 0 DMA generates an interrupt request for the
corresponding start source to the interrupt controller during operation, and the DMAENi0~DMAENi7 of
the corresponding DMAENi (i=0~2) registers Position 0 (disable startup). When the RPTINT bit of the
DMACRj register is 0 (interrupt is prohibited), even if the DMACTj register becomes 0 data transfer, no
interrupt requests are generated, and the DMAENi0~DMAENi7 bits are unchanged from 0.
The register function and data transfer of the repeating pattern are shown in Table 16-8 Figure
16-18, respectively.
Table 16-8 Register Functions for Repeat Pattern
The register name
symbol
function
DMA block size register j
DMBLSj
The size of the data block to be transferred by 1
start
DMA transfer count register j
DMACTj
The number of times the data was transmitted
DMA transfer number of times to reload register j
DMRLDj
Reload the value of this register into the DMACT
register.
(Initialize the number of data transfers)
DMA source address register j
DMSARj
The address of the source of the data
DMA destination address register j
DMDARj
The destination address of the data
Note j=0~23
