Chapter 7 Real-Time Clock
7.1 Function of real-time clock
The real-time clock has the following functions.
 Hold counters for years, months, weeks, days, hours, minutes, and seconds, up to 99 years.
 Fixed cycle interrupt function (period: 0.5 seconds, 1 second, 1 minute, 1 hour, 1 day, 1 month).
 Alarm interrupt function (alarm: week, hour, minute).
 1Hz pin output function
7.2 Structure of real-time clock
The real-time clock consists of the following hardware.
Table 7-1 Structure of real-time clock
project
structure
counter
Internal counter (16-bit).
Control registers
Peripheral enable register 0 (PER0.bit7).
Real-time clock selection register (RTCCL).
Real-time clock control register 0 (RTCC0).
Real-time clock control register 1 (RTCC1).
Second Count Register (SEC).
Minute count register (MIN).
The hour count register (HOUR).
Day Count Register (DAY).
Week count register (WEEK).
Month count register (MONTH).
Year Count Register (YEAR).
Clock error correction register (SUBCUD).
Alarm clock minute register (ALARMWM).
Alarm clock hour register (ALARMWH).
Alarm clock week register (ALARMWW).
Note: The reset of the above RTC control registers is only controlled by POR reset.
