12.8.2 LIN reception
In UART reception, UART0 supports LIN communication.
The LIN receives the channel 1 of the Unit0.
UART
UART0
UART1
UART2
UART3
LIN communication support
Yes
No
No
No
Object channel
Channel 1 of SCI0



The pin used
RxD0



interrupt
INTSR0



Limited to end-of-transfer interrupts (disable setting buffer null interrupts).
Error interrupt
INTSRE0



Error detection flag


The length of the transmitted
data
8 bits
Transfer Rate
Note
Max.f
MCK
/6[bps](), Min.f
CLK
/(2×2
15
×128)[bps]
Data phase
Normal-phase output (default: high). Inverting output (default: low).
Parity bits
No parity bits (no parity).
Stop bit
Appending 1 bit.
Data direction
LSB takes precedence
Note It must be used within the scope of the peripheral functional characteristics that meet this condition and meet the
electrical characteristics (refer to the data sheet).
Remark f
MCK
: Operating clock frequency for object channels
f
CLK
: System clock frequency
