12.3.11 Serial output enable register m(SOEm)
SOEm register settings allow or stop the output of serial communication for each channel.
For channel n that allows serial output, the value of the SOmn bit of the serial output register m (SOm)
described later cannot be rewritten by software, and the value reflected by the communication operation is
output from the serial data output pin.
For channel n that stops the serial output, the value of the SOmn bit of the SOm register can be set by
software and output from the serial data output pin. Thus, an arbitrary waveform such as a start condition or a
stop condition can be generated by software.
The SOEm register is set via a 16-bit memory operation command.
The lower 8 bits of the SOEm register can be set with SOEmL and via 8-bit memory operation
instructions.
After the reset signal is generated, the value of the SOEm register changes to 0000H.
Figure 12-15 Format of serial output enable register m (SOEm)
Address: 4004112AH After reset: 0000H R/W
Symbol
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1
0
SOE0
Address: 4004156AH After reset: 0000HR/W
Symbol
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1
0
SOE1
Note Bit15~4 of the SOE0 register and bit15~2 of the SOE1 register must be placed 0 .
Notice m: unit number (m=0, 1) n: channel number (n=0~3).
To Next Page
