V1.2.2

CMS32L051 User Manual |Chapter 12 Universal Serial Communication Unit

www.mcu.com.cn 295 / 703

Chapter 12 Universal Serial Communication Unit

Unit 0 of the universal serial communication unit has 4 serial channels and unit 1 has 2 serial channels,

each channel can achieve 3-wire serial (SSPI), UART, and simple I

C communication function.

The functions of each channel supported by this product are assigned as follows:

Unit

Channel

Used as SSPI

Used as a UART

Used as a simple I

SSPI00

(Support slave select input

function)

UART0

IIC00

SSPI01

IIC01

SSPI10

UART1

IIC10

SSPI11

IIC11

SSPI20

UART2

IIC20

SSPI21

IIC21

When UART0 is used for Channel 0 and Channel 1 of Unit 0, SSPI00 and SSPI01 cannot be used, but

SSPI10, UART1 and IIC10 on channel 2 and channel 3 can be used.

Note The following sections of this chapter describe the cell and channel structure of the 48-pin product.
