V1.2.2

CMS32L051 User Manual |Chapter 22 Power-On Reset Circuit

www.mcu.com.cn 645 / 703

22.2 Structure of power-on reset circuit

A block diagram of the power-on reset circuit is shown in Figure 22-1.

Figure 22-1 Block diagram of power-on reset circuit

basic

voltage

source

VDD

internal reset

signal

22.3 Operation of power-on reset circuit

The timing of the generation of the internal reset signals of the power-on reset circuit and the voltage

detection circuit is shown below.
