2.3 Registers for controlling port functions
The port function is controlled through the following registers.
•
Port Mode Register (PMxx)
•
Port Register (Pxx)
•
Pull-Up Resistor Selection Register (PUxx)
•
Pull-Down Resistor Selection Register (PDxx)
•
Port Output Mode Register (POMx)
•
Port Mode Control Register (PMCxx)
•
Port Set Control Register (PSETxx)
•
Port Clear Control Register (PCLRxx)
•
Port Output Multiplexing Function Configuration Register (PxxCFG).
•
Port Input Multiplexing Function Configuration Register (TI10PCFG, TI11PCFG, TI12PCFG,
TI13PCFG, INTP0PCFG, INTP1PCFG, INTP2PCFG, INTP3PCFG, SDI00PCFG, SCLKI00PCFG,
SS00PCFG, SDI20PCFG, SCLKI20PCFG, SDAA0PCFG, SCLA0PCFG, RXD1PCFG).
•
SPI Port Multiplexing Configuration Register (SPIPCFG)
Note: Assigned registers and bits vary from product to product. For the registers and bits assigned by each product, refer to
Table 2-1. The initial value must be set for the unassigned bits.
Table 2-1 Registers assigned to each product PMxx, Pxx, PSETxx, PCLRxx, PUxx, PDxx, POMxx,
PMCxx and their bits (1/2)
