V1.2.2

CMS32L051 User Manual |Chapter 2 Pin Function

www.mcu.com.cn 56 / 703

2.5.3 EPWM port configuration method

When using the EPWM output control circuit function, the EPWM output pin is fixed and mapped to

P10~P17 as follows:

The port

name

function

Input/output

PxxCFP

PMCxx

PMxx

POMxx

Pxx

remark

P10

epwmo00

output

P10CFG=4'h0

P11

epwmo01

output

P11CFG=4'h0

P12

epwmo02

output

P12CFG=4'h0

P13

epwmo03

output

P13CFG=4'h0

P14

epwmo04

output

P14CFG=4'h0

P15

epwmo05

output

P15CFG=4'h0

When epwmo05 output, keep

CLKBUZ1 output 0

P16

epwmo06

output

P16CFG=4'h0

P17

epwmo07

output

P17CFG=4'h0

When epwmo07 output, please

keep TO02 output 0
