CMS32L051 User Manual |Chapter 26 Option Byte

www.mcu.com.cn 693 / 703

Figure 26-3 Format of User Option Bytes (000C2H)

Address: 000C2H

7 6 5 4 3 2 1 0

FRQSEL4

FRQSEL3

FRQSEL2

FRQSEL1

FRQSEL0

FRQSEL4

FRQSEL3

FRQSEL2

FRQSEL1

FRQSEL0

The clock frequency of the high-

speed internal oscillator

HOCO

64MHz

48MHz

64MHz

32MHz

48MHz

24MHz

64MHz

16MHz

48MHz

12MHz

64MHz

8MHz

48MHz

6MHz

64MHz

4MHz

48MHz

3MHz

64MHz

2MHz

Beyond the above

Disable settings.

Note 1 You must write 1 for bits7 to 5.

2. The operating frequency range and operating voltage range vary depending on the operating mode of the flash. For

details, please refer to the AC characteristics in the data sheet.
