CMS32L051 User Manual |Chapter 5 Universal Timer Unit (Timer4)

www.mcu.com.cn 142 / 703

Example 1

Timer4

Channel 0: Master control

Channel 1: Slave

CK00

Channel 2: Master control

Channel 3: Slave

CK01

Channel Group 1

(multi-channel linked operation function)

Channel Group 2

(multi-channel linked operation function)

 Channel group 1 and channel group 2 can

be different operation clocks.

Example 2

Timer4

Channel 0: Master control

Channel 1:independent channel

operation function

CK00

Channel 3:independent channel

operation function

Channel 2: Slave

CK00

Channel Group 1

(multi-channel linked operation function)

CK01

 Between the master channel and the slave

channel of channel group 1, there can be a

channel as an independent channel operation

function, and the operation clock can be set

independently.
