Figure 5-53 Example of register settings when measuring input pulse intervals
(a) Timer mode register mn (TMRmn).
CKSmn1
1/0
CKSmn0
0
0
CCSmn
0
M/S
Note
0
STSmn2
0
STSmn1
0
STSmn0
1
CISmn1
1/0
CISmn0
1/0
0 0
MDmn3
0
MDmn2
1
MDmn1
0
MDmn0
1/0
14 13 12 11 10 9 8 7 6 5 4 3 2 1 015
TMRmn
operation mode of Channel N
010B: capture mode
operation configuration when start counting
0: when start counting, not to generate INTTMmn and do not generate inverted Phase Timer output.
1: when start counting, generate INTTMmn and generate inverted Phase Timer output.
capture trigger selection
001B: Select Timn pin input valid edge
MASTERmn bit configuration (Channel 2)
0: Independent Channel operation
SPLITmn bit configuration (Channel 1, 3)
0: 16 bit Timer
Count clock selection
0: Select operational clock (fMCK)
operational clock (fMCK) selection
00B: select CKm0 as operational clock of Channel n
10B: select CKm1 as operational clock of Channel n.
01B: select CKm2 as operational clock of Channel 1,3.(only Channle 1,3 can select the value)
11B: select CKm3 as operational clock of Channel 1,3.(only Channle 1,3 can select the value)
Timn Pin input edge selection
00B: Detect falling edge
01B: Detect rising edge
10B: Detect both edges
11B: reserved
(b) Timer output register m (TOm).
bit n
TOm
TOmn
0
0: Output 0 by TOmn.
(c) The timer output enable register m (TOEm).
bit n
TOEm
TOEmn
0
0: Stop the TOmn output by the count run.
(d) Timer output level register m (TOLm).
bit n
TOLm
TOLmn
0
0: Set 0 in the master channel output mode (TOMmn=0).
(e) Timer outputs mode register m (TOMm).
bit n
TOMm
TOMmn
0
0: Set the master channel output mode.
Note TMRm2: MASTERmn bit.
TMRm1, TMRm3: SPLITmn bit.
TMRm0: Fixed to 0.
Notem: Unit number (m=0) n: Channel number (n=0 ~ 3).
