V1.2.2

CMS32L051 User Manual |Chapter 5 Universal Timer Unit (Timer4)

www.mcu.com.cn 184 / 703

Figure 5-61 Block diagram of operation as a single-trigger pulse output function

(single counting mode)

master control channel

operational clock

TImn Pin

Noise

filter

edge

detection

(single counting mode)

slave channel

operational clock

clock

selection

trigger

selection

clock

selection

trigger

selection

Timer count register

mn (TCRmn)

Timer data register mn

(TDRmn)

Timer count register

mp (TCRmp)

Timer data register mp

(TDRmp)

interrupt

control

circuit

output

control

circuit

interrupt

control

circuit

TOmp Pin

interrupt signal

(INTTMmp)

interrupt signal

(INTTMmn)

Note m: Unit number (m= 0,1) n: master channel number (n=0, 2) p: slave channel number (n= 0：p=1, 2, 3, n=2：p=3)
