V1.2.2

CMS32L051 User Manual |Chapter 6 Function of EPWM Output Control Circuit

www.mcu.com.cn 213 / 703

Figure 6-9 Timing diagram for generation and release of INTP0 truncation

(HS_SEL=0, REL_SEL=0)

clk_epwm

timer_tout3

intp0

EPWMO

Generate forced

truncation signal

HI-Z

Software

release

Note: Short pulses may be generated when switching from normal operation to Hi-Z, fixed low or fixed high during

forced cutoff caused by the cutoff signal INTP0, or when returning to the forced cutoff state by immediate release.
