CMS32L051 User Manual |Chapter 2 Pin Function

www.mcu.com.cn 30 / 703

P130CFG

0x048

R/W

00H

P136CFG

0x04e

R/W

00H

P137CFG

0x04f

R/W

00H

P140CFG

0x050

R/W

00H

P146CFG

0x056

R/W

00H

P147CFG

0x057

R/W

00H

Figure 2-10 Format of port output multiplexing function configuration register

symbol

address

after reset

R/W

PxxCFG

pxxcfg[3:0]

see figure above

00H

R/W

By configuring the PxxCFG register, it is possible to map 15 concurrent output functions (TO10, TO11,

TO12, TO13, SDO00, TxD0, SDO20, TxD2, IrTXD, CLKBUZ0, SCLKO00, SCL00, SCLKO20, SCL20, TxD1)

to any port, other than these 15 concurrent outputs can only be mapped to a fixed port.

Psx port function

pxxcfg[3:0]

4'h00

Default concurrent feature/GPIO

4'h01

TO10

4'h02

TO11

4'h03

TO12

4'h04

TO13

4'h05

SDO00/TxD0

4'h06

SDO20/TxD2/IrTXD

4'h07

CLKBUZ0

4'h08

SCLKO00/SCL00

4'h09

SCLKO20/SCL20

4'h0a

TxD1

others

Configuration prohibited
