V1.2.2

CMS32L051 User Manual |Chapter 12 Universal Serial Communication Unit

www.mcu.com.cn 446 / 703

(3) Process flow

Figure 12-120 Timing diagram of the address segment transmission

address field transmit

bit operation

Somn bit operation

shift register mn

SDAr input

SDAr output

SDLr output

address

shift operation

Remarks m: Unit number (m=0, 1) n: Channel number (n=0~3) r: IIC numbers (r=00, 01, 10, 11, 20, 21)

mn=00~03, 10~11.
