CMS32L051 User Manual |Chapter 13 Serial Interface SPI
www.mcu.com.cn 477 / 703
Figure 13-18 Stop step of slave reception
Abort the start of
the setting i
Abort the end of the
setting
transferred, wait for the
transfer to end
Put the SPIE position "0"
to stop the SPI from
running
To use deep sleep mode, stop
the clock of the SPI unit and
set the reset state
The penultimate (n-1)
reads out the data
Note 1: In receive-only mode, the SPI transmission is triggered by reading the value of the SDRI
register. If SPI is not aborted in time, there may be a redundant transmission after the last reading
of the SDRI.
If you want to avoid the last redundant transmission, you can turn off SPIE after reading out the
data for the second time to the penultimate and wait for one SCK cycle. The transfer of SPI will be
aborted after the last data transfer is completed.
