CMS32L051 User Manual |Chapter 14 Serial interface IICA

www.mcu.com.cn 534 / 703

(c)

Start~Code~Data~Data~Stop (Send extension code)

(i)

When WTIMn = 0

ST AD6~AD0 R/W ACK D7~D0 ACK D7~D0 ACK SP

1 2 3 4 5

1:IICSn=1010X110B

2:IICSn=1010X000B

3:IICSn=1010X000B(set WTIMn bit to

Note

4:IICSn=1010XX00B(set SPTn bit to1)

5:IICSn=00000001B

Note： to generate stop condition, must set WITIMn bit to '1' and modify INTIICAn interrupt request signal generation timing

sequence.

SPTn=1

Remark must generate

only generate while SPIEn bit is '1'

any

(ii)

When WTIMn=1

ST AD6~AD0 R/W ACK D7~D0 ACK D7~D0 ACK SP

1 2 3 4

1:IICSn=1010X110B

2:IICSn=1010X100B

3:IICSn=1010XX00B(set SPTn bit to1)

4:IICSn=00000001B

SPTn=1

Remark must generate

only generate while SPIEn bit is '1'

any

Note n=0
