CMS32L051 User Manual |Chapter 14 Serial interface IICA

www.mcu.com.cn 550 / 703

(g) A situation in which arbitration fails because of a stop condition when you want to generate a restart

condition

(i)

When WTIMn = 0

ST AD6~AD0 R/W ACK D7~D0 ACK SP

1 2 3

1:IICSn=1000X110B

2:IICSn=1000X000B(set WTIMn bit to)

3:IICSn=1000XX00B(set STTn bit to1)

4:IICSn=01000001B

STTn=1

Remark must generate

only generate while SPIEn bit is '1'

any

(ii)

When WTIMn=1

ST AD6~AD0 R/W ACK D7~D0 ACK SP

1 2

1:IICSn=1000X110B

2:IICSn=1000XX00B(set STTn bit to1)

3:IICSn=01000001B

STTn=1

Remark must generate

only generate while SPIEn bit is '1'

any

Note n=0
