CMS32L051 User Manual |Chapter 19 Key Interrupt Function

www.mcu.com.cn 624 / 703

Figure 19-1 Diagram of the key interrupt

KR5

KR4

KR3

KR2

KR1

KR0

KRM5 KRM4 KRM3 KRM2 KRM1 KRM0

Key return mode register

INTKR
