V1.2.2

CMS32L051 User Manual |Chapter 23 Voltage Detection Circuit

www.mcu.com.cn 656 / 703

Figure 23-4 Generation timing of the internal reset signal (LVIMDS1, LVIMDS0=1, 1 for option bytes)

low limit of working

voltage range

VPOR=1.51V(TYP.)

VPDR=1.50V(TYP.)

power supply

voltage(VDD)

internal reset signal

VLVD

Time

POR reset signal

LVD reset signal

LVIRF flag

(RESF register)

LVILV flag

LVIMD flag

LVIF flag

not cleared

clear

clear via software

Note V

POR

: The POR supply voltage rise detection voltage

PDR

: The POR supply voltage drop detection voltage
