V1.2.2

CMS32L051 User Manual |Chapter 24 Security Features

www.mcu.com.cn 676 / 703

Figure 24-8 Flow of RAM parity check

parity check

start

RAM parity check

parity check

error occurs

internal

reset occurs

normal

operation

enable reset due to

parity check error

RAM error

handling

confirm parity check

error occurs

disable reset due to parity check error

Read RAMRAM parity check

PRERF=1

Note

Note For confirmation of the internal reset of RAM parity errors, see Chapter 21 Reset Function.
