110| Using the SongBook
3 Go to the Global > MIDI > Midi Out Channel page, and assign the Control op-
tion to one of the sixteen available MIDI channels (the same as on the MIDI
IN will work fine).
4 When done, save these settings to the current MIDI Preset by choosing the
Write Midi Preset command from the page menu.
Selecting SongBook Entries via MIDI
When you are ready to remotely select SongBook Entries, switch to the Style
Play or Song Play mode.
At this point, Havian 30 must receive on the special Control channel the
NRPN Control Change messages #99 (MSB, with value 2) and #98 (LSB, with
value 64) in fast succession, as an initialization string. This string must be
sent only once, unless another NRPN control is sent on the same MIDI chan-
nel before selecting a different SongBook Entry.
After the initialization string has been sent, you must send the selection
string, made of two Control Change messages: CC#06 (Data Entry MSB) for
the thousands and hundreds, and CC#38 (Data Entry LSB) for the tens and
units. The range of the Data Entry controls, in this case, is 0~99 (instead of
the typical 0~127).
The following examples show some typical situations.
▪ Send the following string to select SongBook Entry #77:
Initialization string (CC#99, 98)
Thousands and hundreds (00xx)
Tens and units (xx77)
▪ Send the following string to select SongBook Entry #100:
Initialization string (CC#99, 98)
Thousands and hundreds (01xx)
Tens and units (xx00)
