Double Size |583
Double Size
Double-size effects can only be assigned to the FX2 processors (either in the
A or B FX group).
110: St. Mltband Limiter (Stereo Mltband Limiter)
This is a stereo multiband limiter.
Left
Right
FX Amt
FX Amt
Stereo In - Stereo Out
Gain Adjust
Limiter
Limiter
Limiter
Envelope - Control
Envelope - Control
Envelope - Control
Gain Adjust
Limiter
Limiter
Low
Mid
High
Envelope - Control
Envelope - Control
Envelope - Control
Low
Mid
High
Offset
Band-Pass Filters
Limiter
a Ratio 1.0 : 1…
50.0 : 1, Inf : 1
Sets the signal compression ratio
b Threshold [dB] 40…0 Sets the level above which the compres-
sor is applied
c Attack 1…10 0 Sets the attack time
d Release 1…10 0 Sets the release time
e Low Offset [dB] 40…0 Sets the low range gain of trigger signal
f Mid Offset [dB] 40…0 Sets the mid range gain of trigger signal
g High Offset [dB] 40…0 Sets the high range gain of trigger signal
h Gain Adjust [dB] Inf,
38…+24
Sets the output gain
Src Off…Tempo Selects the modulation source for the
output gain
Amt 63…+63 Sets the modulation amount of the out-
put gain
i Wet/Dry Dry, 1:99…99:1,
Wet
Balance between the wet and dry signal
Src Off…Tempo See DMS (Dynamic Modulation Source)
Amt –100…+100 Amount of modulation source
