EQ and Filters (EQ/Filter) |417
9: Stereo Isolator
This is a stereo effect that separates the input signal into low, mid, and high-
frequency bands, and controls the volume of each band independently. For
example you can separately boost or cut the kick, snare, and hi-hat sounds
from a drum signal in realtime.
D
-mod
D
-mod
D
-mod
Left
Right
FX Amt
FX Amt
Stereo In - Stereo Out
Trim
Isolator
Low
Mid
High
Trim
Low
Mid
High
a Trim 0 …10 0 Sets the input level
b Low/Mid [Hz] 100…500 Sets the frequency at which the low
and mid bands are divided
c Mid/High [Hz] 2000…6000 Sets the frequency at which the mid
and high bands are divided
d Low Gain [dB] –Inf,
– 5 9…+12
Sets the low-frequency gain
Src Of f…Tempo Selects the source that will modulate
low-frequency gain
Amt –72…+72 Sets the amount by which the low-
frequency gain will be modulated
e Mid Gain [dB] –Inf, –59…+12 Sets the mid-frequency gain
Src Of f…Tempo Selects the modulation source for
mid-frequency gain
Amt –72…+72 Sets the amount by which the mid-
frequency gain will be modulated
f High Gain [dB] –Inf, –59…+12 Sets the high-frequency gain
Src Of f…Tempo Selects the modulation source for
high-frequency gain
Amt –72…+72 Sets the amount by which the high-
frequency gain will be modulated
